The Traxxas E-Revo was designed to be "Brushless Ready." Now, with the help of Castle Creations, E-Revo is officially brushless equipped. Power-hungry electric monster truck racers can purchase the ground-breaking E-Revo complete with a factory-installed and programmed Castle Creations Mamba Monster system. This heavy-duty setup includes Castle's 2200kV motor for full 6S LiPo (25.2 volts max) compatibility, which gives E-Revo the ability to exceed 50mph with wheel-lifting torque and brutally quick acceleration. The Mamba Monster controller features a cooling fan and heavy-duty construction with oversized 6.5mm connectors while the motor uses a 5mm rotor shaft for added durability. Secure mounting keeps the ESC and on/off switch in place without relying on servo tape. The E-Revo requires no modifications to handle the extra power; all of the drivetrain and transmission components were designed from the start for exactly this type of high-amp, high-rpm horsepower. Super-Duty Revo driveshafts, Torque-Control slipper clutch, an oversized steel idler gear and rubber sealed bearings are just a few of the features that make E-Revo ready for all the horsepower you can handle. Also new on the E-Revo Brushless Edition is the Traxxas TQ 2.4Ghz radio system that practically eliminates frequency conflicts while delivering the long range and reliability you expect from Traxxas.
Features
Integrated dual battery compartments with quick release battery doors
Scalable battery compartments from sport packs to brutal 6S Lipo power
Dual digital waterproof steering servos deliver 125oz-in of torque and 0.16-sec transit time
Hard-anodized Teflon-coated shock bodies with TiN coated shock shafts
TQ 2.4Ghz DSS radio system
Sealed pivot ball suspension
Sealed limited slip differentials
Hex hardware throughout
Talon tires on 3.8" black chrome Gemini wheels
Castle Creations Mamba Monster Features
Rated for 6S LiPo operation
Low-voltage detection for LiPo use
6.5mm gold-plated bullet connectors
Castle Link compatible for tuning via computer using USB cable
5mm rotor shaft
Specs
Type: 4WD Off road
Scale: 1/10
Length: 22.91 inches (582mm)
Width: 16.38 inches (416mm)
Wheelbase: 14.1 inches (358mm)
Weight: 135oz (3.82kg)
Chassis: Molded Composite Nylon Tub
Suspension: Advanced Suspension Design
Drive Train: Shaft-Driven 4WD
Tire Type: Talon (5.75" x 3.8")
Motor or Engine: Castle Creations Mamba Monster 2200Kv
Speed Control: Castle Creations Mamba Monster Forward/Reverse/Brake
Radio: Traxxas TQ 2.4GHz
Batteries: Two NiCad or NiMH (stick)7.2V or 8.4V (6 or 7 Cell)
Speed: 35+mph (65+mph w/ LiPo Battery)
Gear Pitch: 32-Pitch
Wheel Size: 3.8" Gemini (black-chrome) with 17mm splined hex
Kit/RTR: RTR
Shock Type: precision aluminum shocks
Body: ProGraphix
Ball Bearings: Rubber Sealed Bearings
