VEX-276-2163 VEX Robotics Continuous Rotation Motor Kit <p> <font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Expand
your robot's navigation with the continuous-rotation motor. This motor
is made to mate perfectly with the drive shafts of the Vex Robotics
System. </font></p>
<p><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Includes
everything you need for assembly: 1 motor, 4 mounting screws and
replacement gear set<br>
For use with Robotic Starter Kit #276-2151</font></p>
<table width="100%" border="1" cellspacing="0" cellpadding="0">
<tr>
<td colspan="2"><font color="cccccc" size="2" face="Arial, Helvetica, sans-serif">Technical Info </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Free Speed </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">100 rmp at 7.5V </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Stall Torque </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">6.5 in-lbs. </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Min/Max Voltage </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">4.4 - 15V (Motor life will be reduced operating outside the VEX Controller range of 5.5 - 9.0V)</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">PWM Input </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">1ms - 2ms will give full reverse to full forward; 1.5ms is neutral </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Nominal Dead Band </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">1.47ms - 1.55ms </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Weight</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">0.21 lbs. </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Wiring </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Black - ground; Orange - (+) power; White - PWM motor control signal</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Current Draw </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">5mA to about 1 Amp. at stall per Motor </font></td>
</tr>
<tr>
<td colspan="2"><font color="cccccc" size="2" face="Arial, Helvetica, sans-serif">List of Contents </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">1</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">VEX Continuous Rotation Motor </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">1</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">VEX motor gear set (4 total gears, 1 replacement for each gear inside)</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">2</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">6-32 x 1/4in. Screws </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">2</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">6-32 x 1/2in. Screws </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">1</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Clutch Post </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">1</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Inventor's Guide Insert </font></td>
</tr>
</table>
