VEX-217-2000 VEX Pro CIM Motor <p><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">The CIM motor can be used to power a drivetrain or other mechanism on large competitive robots. FIRST legal. 12V DC. </font></p>
<table width="100%" border="1" cellspacing="0" cellpadding="0">
<tr>
<td colspan="2"><font color="cccccc" size="2" face="Arial, Helvetica, sans-serif">Specs</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Output Shaft Size </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">8mm (0.314in.) with 2mm keyway </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Free Speed </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">5310 rpm (+/-10%) </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Free Current </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">2.7A</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Maximum Power</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">337 W (at 2655 rpm, 172 oz-in, and 68A) </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Stall Torque </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">2.42N-m (343.4 oz-in.) </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Stall Current </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">133A</font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Mounting Holes </font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">(4) #10-32 tapped holes on a 2in. bolt circle </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Size</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">2.5in. CIM Motor </font></td>
</tr>
<tr>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">Weight</font></td>
<td><font color="00ff66" size="2" face="Arial, Helvetica, sans-serif">2.8lbs.</font></td>
</tr>
</table>

VEX Pro CIM Motor
The CIM motor can be used to power a drivetrain or other mechanism on large competitive robots. FIRST legal.
$34.99
Robot MarketPlace - VEX Pro CIM Motor
CLOSE X
Loading Image...
Motors
    Motors - Brushed


Click photo to enlarge.

VEX Pro CIM Motor
Part# VEX-217-2000



Please see this product on the new Robot MarketPlace web site. Click here






General Product Information
Other Documentation
Reviews & Comments

The CIM motor can be used to power a drivetrain or other mechanism on large competitive robots. FIRST legal. 12V DC.

Specs
Output Shaft Size 8mm (0.314in.) with 2mm keyway
Free Speed 5310 rpm (+/-10%)
Free Current 2.7A
Maximum Power 337 W (at 2655 rpm, 172 oz-in, and 68A)
Stall Torque 2.42N-m (343.4 oz-in.)
Stall Current 133A
Mounting Holes (4) #10-32 tapped holes on a 2in. bolt circle
Size 2.5in. CIM Motor
Weight 2.8lbs.
