RoboteQ XDC2460 Dual Channel 150A Brushed DC Motor Controller
Part# RTQ-XDC2460




Please see this product on the new Robot MarketPlace web site. Click here








General Product Information
Other Documentation
Reviews & Comments

Description
Roboteq's XDC2460 controller is designed to convert commands received from an RC radio, Analog Joystick, wireless modem, PC (via RS232 or USB) or microcomputer into high voltage and high current output for driving one or two DC motors. Using CAN bus, up to 127 controllers can be networked at up to 1Mbit/s on a single twisted pair.

The controller features a high-performance 32-bit microcomputer and quadrature encoder inputs to perform advanced motion control algorithms in Open Loop or Close Loop (Speed or Position) modes. The XDC2460 features several Analog, Pulse and Digital I/Os which can be remapped as command or feedback inputs, limit switches, or many other functions.

The controller's two motor channels can either be operated independently or mixed to set the direction and rotation of a vehicle by coordinating the motion of each motor. The XDC2460 is available in a single channel version with double the current.
Numerous safety features are incorporated into the controller to ensure reliable and safe operation. The controller's operation can be extensively automated and customized using Basic Language scripts. The controller can be reprogrammed in the field with the latest features by downloading new operating software from Roboteq.

Applications

Industrial Automation
Tracking, Pan & Tilt systems
Terrestrial and Underwater Robotic Vehicles
Automatic Guided Vehicles
Police and Military Robots
Flight simulators
Telepresence Systems
Animatronics

Specifications

Power
Motor Type: Brushed
DC Max Voltage: 60
Number of Channels: 2
Direction: Forward/Reverse
Max Amps per Channel: 150
Continuous Amps per Channel: 80
ON Resistance (mOhm): 3
Power Connections: Wires

Commands & Feedback
Analog: Yes
RS232: Yes
USB: Yes:
CANbus: Yes
RC Pulse: Yes
MicroBasic Scripting: Yes
Control Loop (ms): 1
Regenerative braking: Yes

I/O
Max Analog Inputs: 6
Max Digital Inputs: 6
Digital Outputs: 2
Max Pulse Inputs: 4
Encoder: Yes

Mechanical
Cooling: Heatsink Extrusion
Dimensions: 228mm x 140mm x 40mm
Weight: 1350g
