Robot MarketPlace - RoboteQ MBL1330 Single Channel 75A Brushless DC Motor Controller

Roboteq's MBL1330 is a high-current controller for hall-sensor equipped Brushless DC motors. The controller uses the position information from the sensors to sequence power on the motor�s 3 windings in order to generate smooth continuous rotation. The controller also uses the Hall sensor or encoder input information to compute speed and measure travelled distance inside a 32-bit counter. The motor may be operated in open or closed loop speed mode.

The MBL1330 accepts commands received from an RC radio, Analog Joystick, wireless modem, or microcomputer. Numerous safety features are incorporated into the controller to ensure reliable and safe operation.

The controller's operation can be extensively automated and customized using Basic Language scripts. The controller can be configured, monitored and tuned in realtime using a Roboteq�s free PC utility. The controller can also be reprogrammed in the field with the latest features by downloading new operating software from Roboteq.

Power
Max Voltage	30V DC
Number of Channels	1
Direction	Forward/Reverse
Max Amps per Channel	75A
Continuous Amps per Channel	50A
ON Resistance	3 mOhm
Power Connections	Faston
Command
Analog	Yes
RS232	Yes
USB	Yes
CANbus	No
RC Pulse	Yes
MicroBasic Scripting	Yes
Control Loop (ms)	1
Input/Outputs
Analog Inputs	4
Digital Inputs	6
Digital Outputs	2
Pulse Inputs	5
Encoder	Yes
Physical
Cooling	Conduction plate
Cables	No cables included.
Dimensions	140 x 113 x 20mm
Weight	100g
