FEATURES
Charges 1-6 cell LiPo, LiHV, Li-Ion and LiFe batteries
1-15 cell NiCd, NiMH batteries
2-20V lead acid batteries
Charges two different types of batteries simultaneously
60W max, 400-840°F soldering iron with two tips, stand and sponge
128x64 LCD screen
USB port for PC control and firmware upgrade
Smart phone control and monitor via WiFi module (requires WiFi
Module, not included, order HRCP4228)
LiPo battery meter
Battery internal resistance meter
Capacity limit
Processing time limit
Ten battery memory
Charge Master software allows monitoring pack voltage, cell voltage
and other data via personal computer, as well as initiating and
updating firmware
Re-peak mode for NiMH/NiCd batteries ensures full charges
Delta peak sensitivity terminates charge when battery voltage
exceeds threshold
One year limited warranty from the date of purchase through HITEC
RCD USA, INCINCLUDES
X2 AC Pro Charger
AC Power Cord
Universal Balancing Board
XH Balancing Board
Two Charging Cables
2-pin T-Type Charge Lead
XT60 Charge Lead
Soldering Iron w/Pencil and Chisel Tips, Stand and Sponge
Instruction Manual
SPECIFICATIONS
AC Input: 100 - 240V AC
DC Input: 11 - 20V DC
Total Charge Circuit Power: 200W AC input (Support Power Dist.)
channel A 200W, channel B 100W DC Input
Charge Current Range: Channel A 0.1-20A/channel B 0.1-10A
Discharge Current Range: 0.1 - 5.0A x 2
Discharge Circuit Power: 10Wx2
Current Drain for LiPo Balancing: 300mA per cell
Capacity Range: 100-50,000mAh
Dimensions: 7.76 x 7.17 x 2.80" (197 x 182 x 71mm)
Soldering Iron: 60W max 392°F - 842°F
60W max 200°C - 450°C
