FingerTech tinyESC v2.3 Part# 0-FT-TINYESC-V2 |
|
$33.99 |
|
These upgraded tinyESCs replace both versions of the old style controller. All the features of the expensive "w/ BEC" version at the price of the basic! Version 2.3, now with 50% higher continuous-current capacity! Thicker pcb traces shunt heat away from the driver chip faster - meaning you can run larger motors! These are the smallest and lightest motor controllers currently manufactured for RC hobby robotics. They take up very little space but can handle more than enough motor current for small robots. The tiny ESC v2 includes a Battery Eliminator Circuit. If there is no 5V supply present on the robot, this will power the radio receiver from the main battery. *If 5V already exists, simply pull the red 5V pin from the connector. Battery Voltage: 6.5V - 36V Motor Current: 1.5A continuous. For robots, usable continuous current is 2.0A. Circuit board size: 1.27x1.27x0.41cm (0.5x0.5x0.16in.) Features: The videos show a tinyESC running a powerful 22mm diameter motor that draws over 5A stall at 12V. On the left is 11.1V operation and on the right is 14.8V operation. At 11.1V, the tinyESC runs at full power even with over 2.3kg (5lbs) of weight on the wheel. At 14.8V, it takes 2.3kg (5lbs) before overcurrent protection kicks in. (Remember, that's 5lb per wheel!) Calibration |
