Ideal for 3D models 6-9 ounces and sport and scale models 8-12 ounces, or models requiring up to 85 watts of power.
Type |
Brushless Outrunner |
Size |
180-280 replacement |
Bearins or Brushings |
Ball Bearings |
Recommended Prop Range |
6x5 to 8x3.8 (3 cells) or up to 10x3.8 (2 cells) slow flyer |
Voltage |
7.2-11.1 |
RPM/Volt (Kv) |
1380 |
Resistance |
0.33 ohms |
Idle Current |
0.40A at 8V |
Shaft Diameter |
0.125 in (3.17mm) |
Overall Length |
0.90 in (22mm) |
Weight |
24g (0.8 oz) |
Overall Diameter |
1.10 in (28mm) |
Continuous Current |
7A |
Maximum Burst Current |
9A for 15 seconds |
Cells |
2-3S LiPoly or 6-10 NiCad/NiMh |
Speed Control |
8-10A Brushless |
Needed to Complete
8-10A Brushless ESC |
6x5 to 8x3.8 (3 cells) or up to 10x3.8 (2 cells) slow flyer |
2-3S LiPoly or 6-10 NiCad/NiMh |
|
